IBM DB2 to ClickHouse: How to Move Your Data
Move IBM Db2 into ClickHouse with Airbyte. Why CHAR columns arrive padded, dates are often not dates, and where to put the cleaning and FINAL.
Moving IBM Db2 into ClickHouse puts decades of transactional history behind an engine fast enough to sit under a live dashboard. Db2 is reliable and well-governed, and asking it to scan millions of rows while running your business is not what it is sized for.
The interesting work here is not the pipeline, it is the schema. Db2 databases are usually old, and the conventions they were built with produce columns that behave oddly once they land in a columnar engine.
IBM Db2 to ClickHouse at a glance:
Why move data from IBM Db2 to ClickHouse?
Two situations account for most of these pipelines.
The first is serving analytics without touching the mainframe or the licence. Db2 capacity is expensive and carefully managed, so a columnar copy answering dashboard queries removes load from a system where load has a price attached.
The second is joining long-standing transactional records to modern event data. Db2 often holds the history nobody else has, and putting it beside your product or web data is how that history becomes useful rather than merely archived.
What do you need before you start?
The schema review is the item people skip and should not:
A read-only user with access to the tables you need. Created for this pipeline rather than borrowed, so its queries are identifiable when somebody asks what is consuming the instance. The Db2 source documentation covers the connection fields.
A review of the columns you are taking. Specifically which are fixed-width CHAR, which hold dates in a form that is not a date type, and which carry numeric precision beyond what a destination column will hold comfortably.
A cursor column per table, where one exists. Something that only increases and is set on every write. Older schemas frequently lack a reliable updated timestamp, and tables without one are limited to full refresh.
A ClickHouse instance and credentials. With permission to create tables in the target database. Think about sort order while you are here, because on a columnar engine that choice affects query performance more than anything in the pipeline.
If your Db2 instance or ClickHouse cluster restricts inbound traffic by IP, add the Airbyte Cloud IP addresses to the allow list before you begin.
How do you build a Db2 to ClickHouse pipeline in Airbyte?
Step 1: Review the schema with somebody who knows it
Sit down with whoever maintains the database and go through the columns you intend to take. Old schemas carry conventions that made sense when they were designed, and the person who can explain them is a better source than the column names, which are frequently abbreviated beyond recognition.
Step 2: Configure the Db2 source
Click Sources in the left navigation, then New Source, and select IBM Db2, following adding a source. Supply the host, port, database and read-only credentials, along with your SSL configuration if the instance requires it.
Step 3: Configure the ClickHouse destination
Click Destinations, then New Destination, and select ClickHouse, following adding a destination. Supply host, port, database and credentials. Deduplication uses the ReplacingMergeTree table engine, and your sort order should reflect how people actually filter the data.
Step 4: Nominate cursors and schedule off-peak
Click Connections, then New connection, select your tables, nominate a cursor field where one exists and choose a sync mode. Schedule it when the Db2 instance is least busy, because this is another client competing with whatever that system is running.
Then build a view over the landed tables that does the cleaning described below, rather than asking every consumer to repeat it.
What will an old Db2 schema do to your columns?
Three things, and all of them are easier to handle deliberately than to discover later. Fixed-width CHAR columns arrive padded with trailing spaces, so a product code stored as CHAR of length ten carries six spaces after a four character value, and every join or filter against it fails unless you trim.
Dates are the second. Schemas designed before date types were universally trusted often store them as integers in a numeric form, or as fixed-length strings, so what looks like a number is a date and sorting it works while date arithmetic does not.
Numeric precision is the third and the one worth checking against real values. Db2 DECIMAL columns can carry precision beyond what a destination type holds comfortably, and on financial data a silently rounded figure is worse than an error. Confirm the ranges actually in use rather than the declared maximums.
Why put the cleaning in a view?
Because the alternative is every analyst independently discovering that a join fails on trailing spaces. A view trimming CHAR columns, converting the numeric dates and naming the abbreviated columns readably turns a faithful copy of an old schema into something people can use without a briefing.
That same view is where FINAL belongs for anything needing an exact count. ReplacingMergeTree collapses duplicate rows during background merges rather than on write, so a query run shortly after a sync can return rows that the same query returns cleanly later.
Keeping the landed tables untouched underneath is worth doing too, because it means you can revisit a cleaning decision without re-reading from Db2. On a source where the instance has limited capacity and a licence attached, not having to go back is worth more than the storage costs.
Frequently asked questions
Why do my joins fail on values that look identical?
Fixed-width CHAR columns arrive padded with trailing spaces. Trim them in a view so every consumer gets the same behaviour.
Why is my date column a number?
Older Db2 schemas frequently store dates as integers or fixed-length strings. Convert them in your view, and confirm the format with whoever maintains the database.
Why does my count change between queries?
ReplacingMergeTree removes duplicates during background merges rather than immediately. Query with FINAL where exact figures matter.
What if a table has no suitable cursor column?
It is limited to full refresh, which on a large historical table is heavy. Schedule those separately and less frequently than the tables that can sync incrementally.
Can I do this without writing code?
The Airbyte setup is entirely UI-driven. The cleaning view is SQL, and on this source it is the step that makes the dataset usable.
Get your Db2 data into ClickHouse
Review the schema with somebody who knows it before anything technical, because old conventions produce columns that look fine and behave badly. Then build one cleaning view that trims, converts and renames, add FINAL where counts must be exact, and schedule against the instance's quiet hours.
